Spin Coating is a standard laboratory procedure which involves depositing thin films of materials, often polymers, uniformly on flat substrates by employing the concept of centrifugal force. The substrate needs to be rotated at high speed to achieve the desired thickness of the coating material.
Easy to use, safe and inexpensive, this method is extremely desirable for many applications where high quality of layers are required. Despite of the process simplicity, several experimental and theoretical investigations appeared in the literature explaining the dependence of the spin coating process on the electrical, optical and morphological characteristics of the films.In such a way that the control of the fluid flow and the fluid evaporation are essential to meet uniform thin films.Since both contribute to the overall rate of the thinning during spinning of the fluid on the substrate.For example, if there are no evaporation of the solvent, the film thickness at long time varies with spin speed and time.While in the presence of constant or variable solvent evaporation rates,Steady-State film thickness obeys h α Ω - ⅔ or h α Ω - ½.
EZspin & SpinNXG Series Overview
At Apex, we understand how important it is to be precise in such a process. So we bring to you two Spin Coater Series EZspin & SpinNXG which are not only remarkable for its high accuracy but also for being very user-friendly.
Basic Spin COating system
EZspin-SD
EZspinSD has a Teflon coated Working chamber of 6 inches diameter and also includes a transparent photo-resist safety lid over the Working chamber making spin coating a hassle free experience.
advanced spin coating system
EZspin-PR
The advanced model EZspin-PR continues to deliver high precision and reliability of its predecessor, the ’SpinNXG’ series of Spin Coaters. It is designed to ensure consistent and uniform Thin Film deposition every time. Its enhanced features like PTFE coated working chamber of 200 mm diameter and Higher non-volatile memory along with user friendly interface makes EZspin-PR an ideal choice for modern Laboratories and Research facilities. It offers flexibility and control with 15 preset editable Programs, each having 20 steps for multi-speed Spin Coating processes.
ADVANCED PROGRAMMABLE SPIN COATING SYSTEM
EZspin-A1
Reproduciblity of film thickness in Spin Coating Process depends on precise rotational speed. Apex brings to its customers a new state-of-the-art spin coating system, model EZspin-A1 with unique speed range of 50 - 12000 RPM along with a load of other unique features.
spinNXG-P1
Multi-speed spinning is an advanced process of Spin Coating. Thus we introduce an entry-level Programmable Spin Coater SpinNXG-P1. The 2 Preset editable programs allows the user to manage the spinning protocol upto 10 steps on each program. Thus affordability and easy to use firmware makes SpinNXG-P1 the best choice in this category.
basic programmable spin coating system
advanced programmable spin coating system
spinNXG-P1A
SpinNXG-P1A is based on the performance and accuracy of SpinNXG-P1 with Teflon coated working chamber of 8 inches diameter. Besides it comes equipped with higher memory storage. It has 15 preset editable programs, each program has 20 steps to be used during multi-speed spin coating process. Thus it gives the user the freedom to use different programs for different protocol of experiment.
EZspin-A2
Handling larger substrates is no longer an issue in spin coating. Here comes the EZspin-A2 with 250mm diameter of working chamber which can accommodate various substrate sizes. It’s adjustable speed range from 50 - 12000 RPM provides flexibility for various coating requirements.
Safety becomes a significant concern when dealing with high angular momentum. Thus, EZspin-A2 comes pre-loaded with integrated Lid-sensor ensuring safety during the coating process. It is also equipped with an in-situ dispensing port over the photoresist Lid and a 7” colour touch-screen display for easy operation and monitoring.
computer controlled spin coating system
